Description
Feature:Model 1.54 inch E-Paper Display Module 2.13 inch E-Paper Display Module 2.9 inch E-Paper Display Module Dimensions (bare screen) 38 x 31mm 59 x 29mm 79 x 37mm Dimensions (drive board) 47 x 38mm 73x34 mm 92 x 38mm Display size 29 x 29mm 50 x 24mm 68 x 31mm Operating Voltage 3.3V-5V Communication Interface SPl Port PH2.0(8P) Dot pitch 0.138x0.138 0.299 x 0.299 0.138x0.138 Resolution 200 x 200 202 x 104 296x 128 Display color Black/white Gray scale 2 Partial refresh 0.3s Global refresh 2s Refresh power consumption 26.4mW(typ.) Standby power consumption <=0.017mW
Pin Function:
VCC: 3.3V /5VGND: GNDDIN: SPI communication MOSI pinCLK: SPI communication SCK pinCS: SPI chip select pin (active low)DC: data/command control pin (high level means data, low level means command)RST: External reset pin (low level reset)BUSY: Busy state output pin (high level indicates that the module is in the previous process)
Size:
Fixing hole: 3mmHole distance:
1.54 inch: 1700*1100mil, 43.18*27.94mm2.13 inch: 2600*1100mil, 66.04*27.94mm2.9 inch: 3400*1300mil, 86.36*33.02mm
Package includes:
