Description
More details: Click here to openDescription:
1. Working voltage: 12V (12V version).2. Working current: standby 8MA, 32 relays are open 1.15A3. "open" "close" "Momentary" "Self-locking" "Interlock" "Delay" 6 Commands4. MODBUS RTU command5. Under the "Delay" command, the maximum delay is 255 seconds6. MODBUS commands can be made serial Hyper Terminal (serial assistant) or "Modbus Poll" Enter.7. Under the MODBUS command mode, it can support up to 64 devices in parallel8. Size: 180 * 90 * 20mm(Only Board); 195 * 115 * 43mm(with DIN Rail Box)9. Weight: 296g (Only Board); 475g ( with DIN Rail Box)10. Maximum load: 10A / 250V AC
DIN rail Box parameters:
Product model: UM100Color: GreenWidth: suitable for PCB board width UM100(100mm)Insulation grade: Flame-retardant VO gradeBackplane length: suitable for 190 mm PCB boardsNet weight: 170gInstallation: DIN35 and C45 rail
Application:
Automated industry PLCSmart Home,Home Automation ,Wiser Home;IP PTC CameraSecurity MonitoringIdentification systemMotor FW & BW?LED Home lightingDoor LockDIY electronic
Package included:
1 x 32 channel RS485 relay module
