12V Electric Heated Handlebar Grip Cover Waterproof Hand Warmer Winter Motorbike Motorcycle

Description

Specification: Product Name 12V strap type non-slip five-speed heating electric handle cover Product Model ZH-1314A1 Product Net Weight 220G Product Gross Weight 395G Product Packaging Black thickened high-end paper box Packing Size 173 133 70mm Input Voltage DC12V Working Voltage DC 12.2V because this product has protection against power loss, if it is lower than 12.2V, the product cannot be used Heating Sheet And Strap Size Length 10.5cm, width 9.5cm, strap length 64cm Product line length 12.5CM the connecting wire length of the heating element 104CM the heating element to the switch 150CM the switch to the terminal manual measurement, there will be some error, please refer to the actual situation Working temperature -30 degrees C--- , 100 degrees C Power and temperature control value first gear red : 18W,85 degrees C, second gear orange : 14W,75 degrees C, third gear yellow : 10W,60 degrees C, fourth gear green : 8W ,55 degrees C, Five gears blue : 6W,50 degrees C The above data are all obtained from experiments. The specific values may fluctuate slightly due to changes in objective factors such as voltage and environment, which are for reference only Fuse 5A product material Fabric Pure plastic PVC Bandage Polypropylene Heating Sheet Composite fiber heating wire Product Accessories 3M glue 1, cable tie 5, stainless steel L bracket 1, strap 2 Installation Method 3M glue sticking and fixing, L bracket lens holder fixing Wiring Method: ① The red wire is connected to the positive electrode of the battery, and the black wire is connected to the negative electrode of the battery. ② If the car has an SAE plug, you can directly plug the SAE plug on the line into the SAE plug of the car. Instructions: 1 VIN 11.7V, do not turn on, VIN 12.2V, LED flashes for 5 seconds 1hz 50 percent to turn off. 2 Working status: indicator light is always on first gear: red always on, second gear: orange on, third gear: yellow, always on, fourth gear: green on, fifth gear: blue on 3 Click on the key: switch gears Product advantages: 1 There is reverse connection protection and anti-surge protection. 2 Pure rubber PVC fabric, waterproof, abrasion-resistant, tear-resistant, anti-inward fold, anti-aging, water-alkali resistance 3 Built-in intelligent temperature control chip, five-speed adjustable temperature, intelligent temperature control is more convenient. 4 10 seconds rapid heating, large heating area. 5 The heating piece is fixed by straps, which is convenient and quick, and does not damage the handlebars. 6 IP67 waterproof level, even if the switch and handle cover are soaked in water, they can work normally. When the handle cover needs to be cleaned, just unplug the plug to wash it with water, which is very convenient. pay attention: 1 Please select the appropriate gear according to the ambient temperature. Under low temperature conditions, when the temperature of the electric heating grip cover cannot be sensed in time due to the numbness of the hand, please use the low or medium gear first to prevent high temperature burns. 2 This product is only suitable for motorcycles with 12V batteries. Please confirm the voltage of your car before installation, and read the installation diagram carefully. Incorrect voltage and wiring will cause damage to the components. 3 This product can only be installed on the handlebars of motorcycles to be energized. You can use a battery to test whether the product is properly energized before installation. 4 It is strictly forbidden to energize and work when not riding empty burn to prevent the electric handle cover from being overheated and damaging the handlebar. 5 It is recommended to connect the electric door lock wire for the wiring. Most models have a black positive pole and a green negative pole. For specific conditions, it is recommended to use a multimeter to measure. Package Inlcluded: 1 X 12V strap type non-slip five-speed heating electric handle cover
