Description
Features:?
1. BaoFeng UV-S9 PlusTri-band radio is upgrade of UV-5R. High Power .2. With optional methods to charge the battery.Multiple charging mode.3. Frequency Range: VHF: 136-174MHz (RX/TX), UHF: 400-520MHz (RX/TX),220-260Mhz With 2 x Antenna (One is Specifically for 220-260Mhz?65-108MHz (Only commercial FM radio reception). Channels:128 groups of storage channels,Broadband (Wide) 25khz / Narrowband (Narrow) 12.5khz Selectable.4. Larger Capacity Li-ion Battery Equipped with a 2800mAh Li-ion battery. UV-S9 Plus Tri-band is light weight and handy.Simply press PTT key to talk: even at night by switching on the built-in LED flashlight and built-in VOX Function hands-free communication.
Specification:? GeneralFrequency range 136-174MHz(Rx/Tx)
200-260MHz(Rx/Tx)
400-520MHz(Rx/Tx)Memory channelsUp to 128 channelsFrequency stability2.5ppmFrequency step2.5/5/6.25/10/12.5/25KHzAntenna impedance50 OHMOperating temperature-20°C-60°CSupply voltageRechargeable Lithium-Ion 7.4VBattery Capacity2800mAhConsumption in standby<=75mAConsumption in reception380mAConsumption in transmission<=1.4AMode of operationSimplex or semi-duplexDimensions110x58x32mmWeight130g(approximate) TransmitterRF power10W/1WModulation typeFMEmission class 16K øF3E/11KøF3E(W/N) Maximum deviation<=±5KHz/<=±2.5KHz(W/N) Spurious emission<-60dB Receiver Receiver sensitivity0.2µV (at 12 dB SINAD) Inter modulation60dB Audio output1000mW Adjacent channel selectivity65/60dB
Package Included:?1 x BaoFeng UV-S9 (136-174Mhz /220-260Mhz /400- 520Mhz) 1 x 2800mAh Li-ion Battery Pack2 x Antenna (One is Specifically for 220-260Mhz? 1 x Headset1 x Belt Clip1 x Hand Strap1 x Adapter(We will send you the suitable adapter according to your location)1 x Desktop Charger ( 100V ~ 240V )1 x Product Manual1 x USB Cable
