2Pcs DC-DC 5-32V to 0.8-30V Power Supply Step Down Module Adjustable Buck Regulator 5A Constant LED Driver Battery Charging Voltage Board

Description

Overview: The module uses high-quality chips, high efficiency (up to 95%), low heat generation, maximum 5A current, and TI's op-amp control output current, making the overall output very stable.This module uses a low-ESR filter capacitor to reduce ripple voltage to 50mV! Features: Module nature: non-isolated buck moduleRectification mode: asynchronous rectificationWiring port: Input mode: IN+ input positive, IN- input negativeOutput mode: OUT+ output positive, OUT-output negativeInput voltage: DC 5V-32VOutput voltage: DC 0.8V-30VOutput current: Adjustable , Max 5AConversion efficiency: 95% (maximum)Switching frequency: 300KHzOutput ripple: 50mV (maximum) 20M bandwidthLoad adjustment rate: +/-0.5%Voltage regulation rate: +/- 2.5%Operating temperature: -40°C to +85°CSize: 51 x 26.3 x 14 (length x width x height) (mm) Package Included: 2 x DC-DC 5A Adjustable Buck Regulator Power Supply Module
