Description
Description:All model was be equipped with UART and bluetooth function, bluetooth module, sampling cables and NTC.Activate BMS:Method 1: Please press the button on the bluetooth module or power display boardMethod 2: Please use conventional charger to activate by charging. Notice: the charge voltage is more 2~3V voltage than battery pack's to charge.BMS for e-bike,e-bicycle,e-scooter and energy storage
Main Functions Description:
Over-charging protection: YesOver-discharging protection: YesOver-current protection:YesTemperature protection: YesDisconnect protection: YesShort Circuit Protection: YesShort Circuit protect recover: YesBalance Function: Yes
Specification:
Discharge current: 30A/40A/60A/80A/100A/120A/150A/200A/250AOver current detect delay: OffloadShort Circuit protection condition: Short circuit of external loadShort Circuit detect delay: 320 uSShort Circuit protection release: OffloadTemp Protect: Charge: -40~65?; Discharge: -40?~70?Working current: 35uASleeping current(when in discharge): 800uAWorking temperature range: -20~70?Storage temperature range: -40~80?
Features:
1. BMS was be manufactured by high quality Mos and IC imported. Keep your battery long cycle service life time.2. Use top quality (A-level) protective integrated circuit IC, from the solution of Japan.3. Extreme low power consumption. The consumption of the whole device is less than 50uA.4. PCB use high anti-corrosion, high water resistance, high impedance ESD conformal Coating.
Package included:
1 x LiFePO4 BMS 16S Battery Protection Board1 x NTC1 x Bluetooth module1 x Bubble Film1 x Connection cable1 x User manual
