Description
Feature:Hardware SpecificationsChipsetGD32VF103CBT6FLASH128KBSRAM32 KBOn-board clock108MHz crystal oscillatorWorking voltage2.7V-3.6VPower1/3 Cortex-M3PeripheralButtonBOOT, RESETLCDST7789, 1.14 IPS, 240x135USBtoTTLCP2104Modular interfaceTIMER, UART, SPI, I2C, PWM, ADC, DAC, CAN, USBOTGWorking temperature range -40°C~ +85°CWeight10gSize51.49 x 25.2 x 10mmPeripheraButton, RGB LED, SD slot, LCDPower Supply SpecificationsPower supply inputUSB 5V/1ACharging current500mABattery input3.7-4.2VUSBTYPE-CPeripheral functions?Timer: Use 16-bit timer * 4
Basic 16-bit timer * 2
Advanced 16-bit timer * 1
?USART * 3
?I2C * 3
?SPI * 3
?CAN * 2
?USBFS (OTG) * 1
?ADC (10 channel) * 2
?DAC * 2 IOStandard 2.54mm pin header interface, leading to all resources of the chipInterfaceLead out LCD, MICRO SD card, JAG and other interfaces
Package includes:
3 x Minimal Development Board
