Description
Technical Parameters:ProjectTechnical indicatorsRemarksbasic requirements5V 40A 200WCommon (No fan)Dimensions200*110*50mm Operating temperature-10°C to +50°C, 20% to 95% RH (no condensation) Storage temperature-20°C to +85°C, 20% to 95% RH (no condensation) Temperature Coefficient0.02~0.05%/°C Heat dissipation methodNatural cooling Rated voltage range220VACACInput voltage range110/240VACInput frequency range50 to 60 HzExcept DC inputInput undervoltage protection115 to 150% intermittent mode Input undervoltage recoveryAutomatic recovery Input overvoltage protection115 to 150% intermittent mode Input overvoltage recoveryAutomatic recovery Electric shock?1%Maximum input voltage full loadMachine efficiency?0.5%Rated input full loadOutput voltage range5V ± 0.5%Three channel outputOutput current40AThree channel outputRipple and noise?150 mVp-p Rise Time?50 ms Output delay?5 S Voltage regulation?0.5% Load Regulation?1% Output overcurrent protectionCurrent drooping Output short circuit protectionIGBT Output overvoltage protectionSoft start protection Input to output>30M? Input to the earth>30M? Output to the earth>30M? Insulation resistance>50M? MTBF100000H
Feature: 1. International AC input range2. High efficiency, low working temperature3. Short circuit,overload,over-current protection4. 100% fully load burn-in test5. Built-in EMI filter, low ripple noise6. Low cost, high reliability7. CE and FCC approval Specification: 1. LED switching power supply using pulse width modulation (PWM) switching technology designed to ensure power supply stability and high efficiency. 2. Product interference, through the EMC testing, ripple ? 50MV. 3. Efficiency above 80%, temperature ? 25 °C. 4. LED switching power supply with overvoltage protection, short circuit protection, overload protection.5. Constant current output to ensure the stability of the power, so that LED lighting effects better and live longer.6. Products have the anti-interference ensures long-life LED strips, reducing the LED lighting decline. Package includes:
1 x Power supply
