Description
Introduction:Banana PI BPI-M2+ is the open source hardware platform, use Alliwnner H5 (option H2+ chip and H3 chip ) chip on board. and mini size only 65mm*5mm, PBI-M2 hardware: 1Ghz ARM7 quad-core processor, 1GB DDR3 SDRAM, 8G eMMC flash on board,and SDIO wifi&BT 4.0 moodule on board.Gigabit ethrnet.
BPI-M2+ series run Android,Debian linux,Ubuntu linux, Raspberry Pi image and others image. Banana PI,it can easily run with the game it support 1080P high definition video output and 4K support, the GPIO compatible with Raspberry Pi B+ .
Banana Pi BPI-M2+ does not support sata port, so you need use USB for hardisk.
Key features:
- Allwinner H5 Quad-core 1.2GHz Cortex-A7 ( option H2+ / H3 ).
- 1GB DDR3
- 8GB eMMC onboard
- HDMI out
- WiFi and bluetooth onboard
- 10/100/1000Mbps Ethernet Port
- CSI camera interface
Hardware specCPUH5 Quad-core Cortex-A7 H.265/HEVC 4KGPUMali400MP2 GPU @600 MHz,Supports OpenGL ES 2.0 Memory1GB DDR3 (shared with GPU)Flash8GB eMMC flash onboard Network10/100/1000 Ethernet WIFI&BTSDIO AP6212 for Wifi &BT 4.0 (option AP6181 AP6335)Video Input A CSI input connector Camera:1 Supports 8-bit YUV422 CMOS sensor interface,2 Supports CCIR656 protocol for NTSC and PAL, 3 Supports SM pixel camera sensor, 4 Supports video capture solution up to 1080p@30fpsVideo OutputsSupports HDMI output with HDCP, Supports HDMI CEC, Supports HDMI 30 function, Integrated CVBS, Supports simultaneous output of HDMI and CVBSAudio Output(s)HDMIUSB port two USB 2.0 HOST, one USB 2.0 OTGmini PCIE1 mini pcie interface & 1 pcie pin define interfaceIRIR input on board GPIO40 Pins Header,compatible with Raspberry Pi B+LEDPower led & Status ledPower Source5V/2A DC input can supply power, but USB OTG input dont supply power OSAndroid, Ubuntu, Debian, Raspberry Pi Image
Click here to know more about BPI-M2+ Series(takes H3 chip version as example)
Package included:
1 x BPI M2+ H5 Board
