Catda SIM7070G NB-IoT / Cat-M / GPRS / GNSS HAT for Raspberry Pi Global Band Support For Raspberry 4B
Catda SIM7070G NB-IoT / Cat-M / GPRS / GNSS HAT for Raspberry Pi Global Band Support For Raspberry 4B - Image 2

Catda SIM7070G NB-IoT / Cat-M / GPRS / GNSS HAT for Raspberry Pi Global Band Support For Raspberry 4B

Original price was: $173,51.Current price is: $121,88.

2000 in stock

SKU: 1774633BANG Category:

Description

Features:
  • Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards
  • Supports communication protocols such as TCP/UDP/HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT
  • Supports GNSS positioning (GPS, BeiDou, GLONASS, Galileo)
  • Onboard USB interface, to test AT Commands, get GPS positioning data, and so on
  • UART control pins, to connect with host boards like Arduino/STM32
  • SIM card slot, supports ONLY 1.8V SIM card (3V SIM card is not available)
  • 2x LED indicators, easy to monitor the working status
  • Baudrate: 300~3686400 bps
  • Common baudrate auto-negotiation: 9600/19200/38400/57600/115200 bps
  • Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32)
Specifications:NB-IOT/CAT-M/2GBandNB-IoT: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85Cat-M: B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85GSM/GPRS/EDGE: 850/900/1800/1900MHzData rateNB-IoT: 136Kbps(DL)/150Kbps(UL)Cat-M: 589Kbps(DL)/1119Kbps(UL)GPRS: 85.6Kbps(DL)/85.6Kbps(UL)EDGE: 236.8Kbps(DL)/236.8Kbps(UL)SIM card supportNB-IoT/Cat-M/2G card (1.8V SIM card ONLY)Applicable regionglobalGNSSReceiver type16-channelC/A CodeBandGPS L1: 1575.42 ± 1.023MHzGLONASS L1: 1598.0625 ~ 1605.375MHzBDS B1: 1559.052 ~ 1591.788MHzGalileo L1: 1575.42 ± 1.023MHzData formatNMEA-0183AntennaActive antennaOTHERPower supply5VOperating voltage5V / 3.3V (configured via 0? resistor)Current consumptionabout 41mA (idle mode)Operating temperature-40°C ~ 85°CStorage temperature-45°C ~ 90°CDimensions30.50mm × 65.00mmSelection Guide
 CAT-M & NB-IOT & GSMCAT-M & NB-IOTNB-IOT SIM7000CSIM7000ESIM7070GSIM7080GSIM7020CSIM7020EApplicable regionsChinaEurope / Africa / Australia / Southeast AsiaGlobalChinaEurope / Africa / Australia / Southeast AsiaBandNB-IoTLTE-FDD: B1/B3/B5/B8LTE-FDD: B3/B8/B20/B28B1/B2/B3/B4/B5/B8/B12/B13/B18/B19
/B20/B25/B26/B28/B66/B71/B85LTE-FDD:
B1/B3/B5/B8LTE-FDD:
B1/B3/B5/B8/B20/B28Cat-MB1/B2/B3/B4/B5/B8/B12/B13/B14/B18
/B19/B20/B25/B26/B27/B28/B66/B85N/AGSMGPRS/EDGE 900/1800 MHzGSM/GPRS/EDGE 850/900/1800/1900MHzN/AN/AGNSSGPS, GLONASS, BeiDou, GalileoN/AData RateNB-IoT(Kbps)34(DL)/66(UL)136(DL)/150(UL)136(DL)/150(UL)26.15(DL)/62.5(UL)Cat-M(Kbps)300(DL)/375(UL)589(DL)/1119(UL)589(DL)/1119(UL) EDGE(Kbps)236.8(DL)/236.8(UL)236.8(DL)/236.8(UL)  GPRS(Kbps)85.6(DL)/85.6(UL)85.6(DL)/85.6(UL)  Software FeaturesNetwork protocolTCP/UDP/HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT, etc.Firmware upgradeUSBUARTHardware InterfacesSIM card slot1.8V/3.3V1.8V1.8V1.8V/3.3VUARTSupports AT commandsSupports AT commands, firmware upgradingUSBSupports AT commands testing, GPS positioning, firmware upgrading, etc.For external power supply ONLYAntenna connectorLTE antenna (SMA) + GNSS antenna (IPEX)LTE antenna (IPEX) + GNSS antenna (IPEX)LTE antenna (SMA)ApplicationsExamplesMeters, remote control, smart home, smart city, intelligent agriculture, and so onPackage includes:
1 x SIM7070G Cat-M/NB-IoT/GPRS HAT1 x LTE Antenna1 x GPS External Antenna (B)
