DC 0-300V 500A Voltage Current Panel Meter Digital Blue Red Dual LED Voltmeter Ammeter With 500A/75mV Shunt

Description

Features:  -2 in 1 function Voltmeter Ammeter, Easy install.-This meter test of Voltages and Amps, power supply can taken from the test circle, no additional power supply-Power supply DC 4.5V - 30V range (Attention: The maximum of input voltage cannot be exceed of 30V, otherwise would be burnt)-Display Range: DC 0V - 300V 0-500A (Please don't exceed the range)-Measuring Range: DC 0V - 300V (Resolution: 1V)-Current: 500A-Resolution: 1A-Display: 0.28" LED digital tube-LED Color : Red Color on Voltmeter and Blue on Ampmeter-Large, high-visibility-Low Power Consumption-Operating Current: less than 60mA-Resolution ±1%+1 digit-Measurement rate: ? 500mS / times-Operating Humidity: 10 to 80% (non-condensing)-Operating temperature -10~65 Deg-Operating Pressure: 80 ~ 106kPa-Size: 48x29x21 mm-Panel cutout 45.5x26.5 mm Package included:  1 x DC 0V-300V 500A Dual LED Digital Voltmeter Ammeter Voltage AMP Power Meter1 x 500A/75mV Shunt
