Description
Overview:The new learning code 12-way remote control switch is upgraded on the basis of the old model, and adopts exquisite industrial control shell design in appearance, and the style is more high-end. The terminal is upgraded. When the interference is strong, the suction cup antenna and the high-sensitivity receiving module can be connected to enhance the signal receiving ability. Another buzzer prompt function.There is no need to use traditional jumpers or DIP switch coding, just let the receiving controller receive and store the wireless signal transmitted by the remote control, and then the supporting use can be realized. If the learned remote control is lost during use, you only need to clear the information stored in the receiving controller. The lost remote control will not be able to remotely control the receiving controller. If you want to regain the right to use, the owner must regain the right to use it. Re-learn it before use. There are 8 switchable output modes.Mainly used in electric doors, windows, lifting equipment, gateways, elevators, industrial control and security industries and other fields.
Main Specifications:
1. Working voltage: DC12-36V, AC220V, AC380V (optional)2. Working temperature: -40?-+80?3. Receiving sensitivity: ?-105dBm4. Working frequency: 315/433MHz (optional)5. Output current: ?3A6. Weight: 0.26KG7. Size: circuit board: 122*87*17mm with shell: 144.8*91*40 mm
Output method:
Signal jog-press the remote control button 1 to learnSignal interlock-press the remote control key 2 to learnSignal self-locking-press the remote control key 3 to learn1-6 Jog, 7-12 way interlock ---- press 4 button on the remote control to learn1-6 Jog, 7-12 self-locking-press the 5 key of the remote control to learn1-4 Jog, 5-12 way interlock-press the 6 key of the remote control to learn1-4 Jog, 5-12 self-locking-press 7 keys on the remote control to learn1-4 channels self-locking, 5-12 channels interlock-press 8 keys on the remote control to learn
Learning methods and steps:
1. Press the learning button of the receiver-the buzzer sounds, indicating that it has entered the learning state.2. Press any key on the remote control-the buzzer stops ringing, indicating that the learning has been successful.
Clear stored information:
Long press the receiver learning button until the buzzer stops, indicating that the stored information has been successfully cleared.
Package includes:
1 x Wireless Controller
