Description
Specification:RF Parameter ValueRemarkWorking frequency 862~893MHzDefault: 868MHz
Transmitting power 30dBmAbout 1W
Receiving sensitivity -147dBmAir data rate is 2.4kbpsAir data rate 0.3k~19.2kbpsDefault: 2.4kbpsTest distance8000m
In open and clear air, with maximum power,5dBi antenna gain, height of 2m,air data rate: 2.4kbps
Hardware ParameterValueRemarkSize82* 62*25mm
Antenna typeSMA-K
InterfaceRS232 / RS485
Baud rate: 1200~115200, default: 9600Package
DB-9 / Screwing
Standard DB9 Hole/3.81 connecting terminal
Buffer
512 bytes bufferAutomatically sub-packaging with 58 bytes per package
Electronic parameterMin.Typ.Max.UnitConditionPower supply101228V
