Description
Specification:RF Parameter ValueRemarkWorking frequency 2400~2505MHzDefault: 2.4GHz
Transmitting power 20dBmAbout 100mW
Receiving sensitivity -102dBmAir data rate is 250kbpsAir data rate -Self-adapted baud rateTest distance2000m
In open and clear air, with maximum power,5dBi antenna gain, height of 2m,air data rate: 250kbps
Hardware ParameterValueRemarkSize82* 62*25mm
Antenna typeSMA-K
InterfaceRS232 / RS485
Baud rate: 1200~115200, default: 9600Package
DB-9 / Screwing
Standard DB9 Hole/3.81 connecting terminal
Buffer
1024 bytes bufferAutomatically sub-packaging with 29 bytes per package
Electronic parameterMin.Typ.Max.UnitConditionPower supply101228V
