Electric Scooter Meter Dashboard For 36V/42V 350W XT30/XT60 Motor Controller

Description

Warning: This Dashboard is the replacement parts for ID: 1647907 and ID: 1679291 ,if you don't have ID: 1647907 or ID: 1679291 ,you should not buy it. OR you can buy ID:1740476 Specification: Voltage DC 31-42V Rated Power 350W Undervoltage 30V Current-Limiting 12-15A 15A scooter could be used,but the speed would be slowly Fitment: Need to be used with controller ID：1679292. Power Display: 1 Voltage 38.2V-42V The first second third fourth fifth lights are always on 2 Voltage 36.6V-38.2V The first second third fourth light is always on 3 Voltage 34.5V-36.6V The first second third lights are always on 4 Voltage 32.8V-34.5V The first second light is always on 5 Voltage 31.5V-32.8V The first light is always on 6 Voltage 30-31.5V The last grid flashes 7 Turn-off of motor with voltage below 31V Error Code: 1 E1 Motor Hall failure 2 E2 MOS MOS fault or motor phase line short circuit fault 3 E3 Brake failure 4 E4 Handlebar failure 5 E5 Undervoltage protection 6 E6 Instrument,control communication failure 7 E7 Overvoltage protection 8 E8 Controller op amp failure 9 E9 Stall protection Package Included: 1 X Dashboard
