Description
Hardware&Software CPU Montage, MT2203 Tuner TC6800 Basic System Fully DVB-T/T2/C compliant Frequency T2: VHF174-230MHZ, UHF470-862MHZ C frequency range: 50-868MHZ Singal Input IEC-TYPE Female Video Decoder H.265 HEVC/H.264/H.263/MPEG-2/AVS/AVS+/VC1 Video Output 480i/480p/576i/576p/720p/1080p/1080i Audio Decoder MPEG-1/2 Layer I/II/III USB 20, 500GB capcity HDMI HDMI 1.4a IR Receiver 38KHZ AC Input 100-240V Accessoried 1 x AV cable, 1 x User manual, 1 x Remote control Size 125 x 62 x 25mm Application Support USB Wifi dongle, IPTV Support Subtitle, Teletext, Multi-language, Parental lock Support PVR for plug-in USB HDD Software upgrades via USB Stores up to 1000 programs and keeps in memory while power off Memory save while power off Powerful and highly effective 7 days EPG function Offers multiple entertainments and games
Feature:
Support languages: Russian, English, Hungarian, Czech, French, Vietnamese, Indonesian, Polish, Thai, PersianDVB-T2, DVB-C dual signal source reception, most countries in Europe, Asia, Africa, Australia can receive signalsThe product supports AV and HDMI output functions, supports ordinary TVs and high-definition TVs
H.265 intelligent encoding, compatible with H.264. It saves 50% bandwidth. More economical and clearer, you can watch more high-definition programsSignal receiving method: Receive outdoor signals through ground waves. It is not a satellite signal receiver, so it cannot receive satellite signalsCPU: Montage MT2203Basic system: DVB-T, DVB-T2, DVB-C compliantFrequency: VHF174~230MHZ, UHF 470~862MHZSingal inputiec: Female typeDecoder: H.265 hevc, H.264, H.263, MPEG-4, MPEG-2, AVS, AVS +, VC1Vedio output: 480i, 480p, 576p, 576i, 720p, 1080p, 1080iAudio Decoder: MPEG-1, MPEG-2, Layer i, Layer ii, Layer iiiUSB type: 2.0Capcity: 500GBIR receiver: 38KHZAC input: 100-240 VACShell material: Full plastic shellWeight: 0.25 kgBare metal size: 125 x 62 x 25mColor box size: 170 x 145 x 35mm
Instruction:
Connect to a WiFi network: Only applicable to the connection of the WIFI module with the 7601 chip. Insert the 7601 module into the USB port, after the machine recognizes the module, find the corresponding network name and enter the correct password to connect to the network
YouTube viewing: You need to use the 7601WIFI module to connect to the Internet to watch
IPTV viewing method:1. Save the program source M3U download and save it on the U disk2. Insert the U disk into the product, after the product recognizes the U disk, turn on the setting function in the menu IPTV3. After the M3U file is recognized, click OK to import the program source and the program list will be displayed4. Remove the U disk, insert the 7601WIFI module to connect to the network, you can watch the imported IPTV program normally
Note:
Please pay attention to check if the device is suitable for your local use before purchasing. The device can only receive and tune to free signals with a frequency of H.265 and below, and cannot support AC3 audio. Some Italian and Spanish channels are not available. Please check before you buy
Package Included:
1 x Grwibeou Set-top Box1 x AV Cable1 x Remote Control
1 x User Manual
