Description
Specifications:Model No.HBV-5640WAModel Size60mm × 8mm × 10.6mmTemperature (Operation) -20°C to 70°CTemperature (Stable Image) 0°C to 50°CAssembly technique SMT (ROSH)Focus FixedObject distance 30CM-infinitResolution 600LW/PH (Center)InterfaceUSB 2.0Power USB bus powerPower consumption 1200 mWPackageAnti-electrostatic trayOperating system request Windows 2000Windows XPWindows 7CertificationsFCC and CEMaximum resolution2592*1944Sensitivity600mv /(lux-sec)Pixel Size 1.4µm x1.4µmMaximum Image Transfer Rate
MJPEGMJPEG 1024x768 30FPS / YUY2 1024x768 6FPS
MJPEG 1280x720 30FPS / YUY2 1280x720 6FPS
MJPEG 1280x960 30FPS / YUY2 1280x960 4FPS
MJPEG 1600x1200 15FPS / YUY2 1600x1200 1FPS
MJPEG 2048x1536 15FPS / YUY2 2048x1536 1FPS
MJPEG 2592x1944 15FPS / YUY2 2592x1944 1FPSS/N Ratio 36dbDynamic Range 68dbPackageCSP,Bare DieLens Type /Lens Construction 3G2P+IRF/No 2.8EFL 1.66mmBFL(Optical) 2.11mmFOV 160TV Distortion <8.5%Relative Illumination (Sensor) 70%R Filter650 ± 10nmDSP Type HBV5640AGC/AEC/Whiter balance AutoOutput FormatsUSB suspend out
