Description
?Specifications:HDCP Version: HDCP1.4HDMI version: HDMI1.4bHDMI resolution: 2160p@30Hz/1080 p@50/60 Hz/1080 i/720 p/1576 i/480 p/480 iSupport video color format: 24-bit/dark color 30-bit, 36-bitAudio output: SPDIF 3.5mm audioMAX Bandwidth: 340MHzExport Rate: 10.2GbpsInput and output TMDS signal: 0.5-1.5 volt p-p (TTL)Input and output DDC signal: 5-volt p-p (TTL)Input cable distance: <=7m AWG26 standard cable HDMIOutput cable distance: <=8m AWG26 standard cable HDMIMaximum work Current: 500mAWorking voltage: dc 5VOperating temperature range: (-15 to 55°C)Operating humidity range: 5% to 90%RH (no condensation)
?Features:
Convert 1 HDMI input to 1 HDMI 1 audio (SPDIF) output 3.5mm analog audio outputInput resolution: up to 3840x2160@30 Hz; 4096x2160@30 HzHDMI realizes the synchronous separation of audio signals. There are three audio mode options: PASS/2.0CH/5.1CHThe LED indicator clearly indicates the working status of the extractor
Package Included:
1 x HDMI Audio Splitter1 x USB Power Supply Line1 x User's Manual
