LC100-A LC Meter 1uH-100H Inductance 1pF-100mF Capacitance Table

Description

More details and instruction: Click to open

Introduction:

LC-100A Meter based on the LC resonant principle, add in high speed microcontroller’s precision computation. The meter has wide measurement range and high precision, it’s measuring range below 1uH and 1pF. Small size, light weight and easy to carry.

Feature:

Supply voltage: 5V
Interface to power supply: Mini USB or ?5.5DC Socket
Display: 1602 LCD
Effective display digits: 4 digits
Measurement method of capacitance, Inductance and Large Inductance: LC Resonance
Measurement method of large capacitance: Charge-discharge

Test Frequency:

L Range, C Range: 500kHz
Hi.L Range: 500Hz~50KHz
Resolution (Hi.C Range): 0.01uF
Resolution (Hi.L Range): 0.001mH
Resolution (L Range): 0.001uH
Resolution (C Range): 0.01pF

Package includes:

1 x LC-100A Meter

Test diagram for reference only, the package does not contain the test tools:

,,,,,
