ECG is a heart rate monitor (electrocardiogram) unit?it can detect the heart rate and output a cardiogram signal. Electrocardiogram (ECG) is a technology that uses an electrocardiograph to record the changes in the electrical activity of the heart during each cardiac cycle. At the signal acquisition end, this ECG module integrates the AD8232 single-lead heart rate monitoring at the front end, the collected ECG signal is processed by the AD8603 low-pass filter, and the 10bit-ADC (AD7476) performs analog/digital signal input to STM32 (built-in heart rate statistics) Algorithm) for signal analysis. Finally, the processing results are output in the form of serial communication to facilitate the acquisition and display of the main control device. In terms of signal output, it adopts front-end/digital full isolation design to enhance equipment stability and safety.
Caution:
This product only allows the use of 5V power input. Please strictly abide by the power input standard when using this product to avoid damage to the equipment or injury.
Features:
ADI front end integration (high signal gain G=100, with DC blocking capability)Serial Data inputHeart Rate Statistics monitoringFront end/digital fully isolated designUltra Precision Op Amp
Package Included:
1x ECG Module3x ECG electrodes6x Adhesive Pads
Applications:
Bioelectric signal acquisitionPortable ECGExercise Tracker
Specification:
ResourcesParameterCommuincation MethodUART 115200bpsAD8232High signal gain G=100 | With DC blocking capability | Common mode rejection ratio: 80 dB (DC to 60 Hz)AD747610bit-ADC | SPI Interface | Fast throughput rate: 1 MSPS | vref 2.8vNet weight18gGross weight101gProduct Dimension54*54*13.2mmPackage Dimension105*65*40mm
Related LinkDatasheet
AD8232AD8603AD7476
Tool
RawDisplay-PCUART Pass Through Firmware
When using the PC-side heart rate reading tool, the device needs to burn the serial port transparent transmission firmware(Before uploading, please change the serial port initialization pin to the actually connected pin) and forward the data to the PC.
Schematic: click to open
Example:
Arduin IDEDownload Arduin Code
Pin Map:
M5StackTX/G13RX/G55VGNDECGRXTXVINGND
