Description
M5Stack's New Cost-effective plug-and-play ESP32 miniature moduleSTAMP PICO STAMP-PICO features an ultra-compact design with two low-power Xtensa® 32-bit LX6 microprocessors at 240MHz on a PCB as tiny and delicate as a postage stamp.It is ideal for any space-constrained or battery-powered devices such as wearables, home automations, smart sensors, and other IoT devices. 1, MULTIPLE STYLE: 5 options of installation, means endless possibilities! (SMT, DIP, flyw1re, Grove interface), with a high-temperature resistant plastic shell, 3D antenna and components can be better protected.2, LOW-CODE DEVELOPMENT: STAMP PICO supports UIFlow graphical programming platform, scripting-free, cloud push; and fully compatible with Arduin0, MicroPython, ESP32-IDF, and other mainstream development platforms to quickly build various applications. 3, HIGH INTEGRATION: STAMP PICO contains 5V->3.3V DC/DC design, GPIOx12, programmable RGB LED x1, button x1, finely tuned RF circuit, providing stable and reliable wireless communication. 4, STRONG EXPANDABILITY: Easy access to M5Stack's hardware and software ecology system: a wealth of sensors, actuators, functional modules, and accessories to choose from, Extremely fast adaptation. Product Features- Chip-set: ESP32-PICO-D4 (2.4GHz Wi-Fi and Bluetooth dual mode)- Support UIFlow graphical programming- Support multiple installation style (SMT, DIP, fly-by-wire)- Integrated programmable RGB LED and button- Miniature in size
Package Included:- 1 x M5Stamp Pico
- 1 x Sticker
- 4 x Pin Headers
- 1 x 90° Grove Connector
- 1 x Hex Key
ApplicationsInstrumentationWi-Fi Remote Monitoring/ControlSmart HomeColor LED ControlFire/security intelligent integrated managementSmart Card TerminalWireless POS
SpecificationsAttributeValueMaster Control ResourceESP32-PICO-D4 | 240MHz dual core, 600 DMIPS, 520KB SRAM, Wi-Fi and Bluetooth, dual modeFlash4MBInput Voltage5V @ 500mAPower consumptionNormal standby:5V@29mA,WIFI STA mode: 5V@60mA,Bluetooth mode data sending status: 5V@84mA, Deep-sleep mode: 5V@0.35mAUIProgrammable physical button x 1, Programmable RGB LED (SK6812) x 1Antenna Type2.4G 3D AntennaWiFi802.11 b/g/n (up to 150 Mbps for 802.11n), spectrum range: 2.4 GHz ~ 2.5 GHz BluetoothBluetooth V4.2 BR/EDR and BLE standard, NZIF receiver, sensitivity up to -97 dBmModule Resource InterfaceADC, DAC, touch sensor, SD/SDIO/MMC host controller, SPI, SDIO/SPI slave controller, EMAC, motor PWM, LED PWM, UART, I2C, I2S, IR remote controller, GPIO, pulse counterIO interface x12G0, G1, G3, G26, G36, G18, G19, G21, G22, G25, G32, G33IO interface spacing2.54mmOperating temperature32°F to 104°F ( 0°C to 40°C )Net weight
