Description
Description:Ultrasonic is an ultrasonic distance measuring sensor unit, with the capability of simultaneous reception and transmission. The ultrasonic probe has a sound frequency of 40KHz, a direction angle of ±20 ° and an accuracy of 1mm. The internal part is calculated by an RCWL-9600 ultrasonic distance measuring chip, and the measurement results can be directly obtained through IIC interface (0x57). The effective distance is 20-1500mm.
Features:
Split transceiverEffective distance 20-1500mmWide angle rangeIIC communication, result output directly
Package Included:
1x Ultrasonic Unit1x Grove Cable(20cm)
Specification:
ResourcesParameterRanging chipRCWL-9600Measuring distance20-1500mmSound pressure level of transmitter108dBAccuracy1mmBlind area20mmReceiver sensitivity-68dBNet Weight9gGross Weight23gProduct Size56*24*12mmPackage Size60*55*16mm
Related Link:
Ceramic Ultrasonic Sensor TC40-10T/R
Example:
ArduinClick here to download code
