Description
Description:X2.730 thermostat is used for electric heating system, such as heating cable, heating film and heating pad.The maximum load is 30A, which means the maximum load is 6900W.The initial temperature difference can be set to 0.5 ?, and the room temperature fluctuation can be kept within 1 ?.
Specification:
-Power supply: 230VAC±10%, 50~60HZ-Load current: 30A max-White color-Display: LCD-Display accuracy: ±0.5 ?-Set temperature range: 5~95 ?-Ambient temperature: -5~50 ?-Power consumption: 2W-Installation box: 86*86mm square or European 60mm round box-Terminal: Wire 2 * 1.5mm2 or 1 * 2.5mm2-Size: 86 * 86 * 34mm / 3.4 * 3.4 * 1.34 inches-Protection level: IP20-Shell material: flame retardant PC
Feature:
1. ECO and comfort mode can be easily set.2. Child lock to prevent unauthorized appearance.3. The thickness of 8mm is ultra-thin design, which matches the wallboard naturally. Package includes:
1 x thermostat1 x 3m external sensor2 x screws1 x User Manual
