Description
Description:4-Relay is a unit integrated with 4-way relay, which is controlled by IIC. The maximum control voltage of relay is AC-250V, rated current is 10A, and instantaneous current can bear 16A. Each relay can be controlled independently. Each relay has a programmable status indicator.
Features:
4-way relayAC-250V/10ALED status indicationIIC communication (0x26)
Package Included:
1x 4-Relay Unit1x Grove Cable(20cm)4x VH-3.96-4P Plug terminal
Applications:
Digital signal switchingProgrammable power switch
Specification:
ResourcesParameterMaximum input voltage250VRated current10AMaximum instantaneous currenta16ACommunicationIIC(0x26)Net Weight40gGross Weight84gProduct Size112*23*18mmPackage Size125*65*22mm
Schematic: click to open
PinMap:
M5Core(GROVE A)SDA(GPIO21)SCL(GPIO22)5VGND4-relay UnitSDASCL5VGND
Example:
1. Arduin IDEclick here to get Arduin example
