Description
>>>Manual: Click here to open<<<Description: - Power Input: DC 12V(8.5-13.5V).- Standby Current: (all relays closed) 18mA, 1 relay open 51mA, 2 relays open 82mA, 3 relays open 112mA, 4 relays open 142mA, 5 relays open 170mA , 6 relays open 198mA , 7 relays open 227mA , 8 relays open 251mA- PC Serial ports RS232 Control Relay;- Power indicator : LED lights; - Output indication : relay output with LED indicators,easy to see working status of the relay;- Communication protocol: UART protocol communication, baud rate 9600kpbs, 8 data bits, one stop bit, no parity. Each data frame contains eight bytes. Two-way data transmission.- Baud rate 9600kbps, 8 data bits, one stop bit, no parity. Each data frame contains eight bytes. - Size : 94 x 62 x 19 mm Control Commands: 1. Reading status(reading the satus of the relay (on/off)) Channel 1 :55 56 00 00 00 01 00 ACChannel 2 :55 56 00 00 00 02 00 ADChannel 3 :55 56 00 00 00 03 00 AEChannel 4 :55 56 00 00 00 04 00 AFChannel 5 :55 56 00 00 00 05 00 B0Channel 6 :55 56 00 00 00 06 00 B1Channel 7 :55 56 00 00 00 07 00 B2Channel 8 :55 56 00 00 00 08 00 B3 2.Relay open (issue this command,Relay open,COM connect to NO) Channel 1 :55 56 00 00 00 01 01 ADChannel 2 :55 56 00 00 00 02 01 AEChannel 3 :55 56 00 00 00 03 01 AFChannel 4
