Description
Description: Input voltage : 3~6VOutput voltage : 6-15.5VMaximum input current : 1.4ALong-term work Current : 1AConversion efficiency : 79-90% Input Interface : USB MaleOuput Interface : 2 PIN XH2.54 Power : Maximum 7WWorking frequency : 1.0MHzOperating temperature : -40 to +85 ?Size: 47.5 x 16mm Applications: 6-15V Low Power Motor6-15V LED LightingHard drive power supply9V 12V 15V Routers and network equipmentWireless communication equipment315M 433M Wireless remote controller Attention : 1. Input voltage can not be greater than the maximum input range.2. Output power can not be greater than the maximum load for a long time.3. Input power must be greater than the output power, because the power consumption of the module itself.Modify Parameter Description: 1.4A current limiting resistor,Remove the resistance, the maximum input current can reach 2A.But IC have "Over Temperature Protection" Function.It will turn off the power MOSFET automatically when the internal junction temperature is over 150 Degrees Celsius. The power MOSFET wake up when the junction emperature drops 30 Degrees Celsius under the OTP threshold temperature Package Included: 1 x USB 5V to 6-15.5V DC DC Converter1 x Cable
