Description
Introduction:This product is suitable for charging safety protection of various batteries and lithium batteries; it can effectively protect the battery from overcharging during the charging process, thereby affecting the service life of the battery. It is a barrier to battery safety.
Parameter:
Product name: Battery charging protection moduleProduct model: XH-M594Power supply voltage: DC8-120VControl voltage: DC8-120VControl accuracy: 0.1VProduct power consumption: <2WScope of application: battery, lithium batteryProduct net weight: 80gProduct size: 79*55*19mm
Settings:
1. Connect the XH-M594 module to the charger and battery, and pay attention to the positive and negative terminals of the Zengchu that are marked with "+"-" symbols;2. The voltage will be displayed on the screen after power-on. When the battery is not connected, the voltage will display as 0 because there is no current.3. Mainboard power supply selection switch, you can switch the current power supply selection module of the XH-M594 module, and you can use the charger GHG or battery power supply BAT4. Long press the'+, key to set the starting voltage, (short press to display the starting voltage) then the starting voltage will flash, then you can press the'+''-, key to set the voltage you want. After setting, wait 5 seconds, the system will automatically save.5. Long press the'-' button to set the stop voltage, (short press to display the stop voltage) at this time, the stop will flash, then you can press the'+''-, button to set the voltage you want. After setting, wait for 5 seconds, the system will automatically save.6. How to restore the factory settings? You can press the "+"_" key at the same time for 3 seconds, it will display 888 and the restoration is complete
Package includes:
1 x Battery charging protection module
