YF-01 DC Over-current Disconnection Protector Current Sensor Detection for Motor Stalls and Stops Rotation Current Monitoring 0.01-9.99A with Digital

Description

Specifications: Model: YF-1Setting range: 0.01A-9.99ASupply voltage: 7-24V DCProduct function: Detect the input current, if the input current exceeds the set value, control the output to power off. It is used for motor stall protection overcurrent protection, overcurrent protection, etc.(During the period when the detection current value becomes large; one starts for 2 seconds; filters out the large current fluctuation caused by the instantaneous application of the inductive load of the motor)Wiring instructions: using pluggable wiring; how many volts are input and how many volts are output. The output controls the positive on and off.Product size: 70cmx45cmx28cmSetting instructions: +: current upper limit value increases /-: current upper limit value decreasesWhen the output terminal is floating; press and hold "+,-" at the same time: error calibration, the current returns to 0. Package Included: 1 x YF-01 DC Over-current Disconnection Protector Current Monitoring Module
